μ-Slide 4 well
An open μ-Slide with 4 wells for use in immunofluorescence and high-end microscopy
All-in-one chamber used for cell culture and microscopy
Observation of the sample through the coverslip-like bottom using high resolution microscopy
Fast and easy immunofluorescence , with no coverslips and no leakage
Cost-effective experiments using small numbers of cells and low volumes of reagents
订购信息
|
Cat. No.
|
Description
|
Pcs./Box
|
RMB
|
|
80422
|
μ-Slide 4 well, Collagen IV, sterile (available only on request)
|
15
|
￥4230
|
|
80423
|
μ-Slide 4 well, Fibronectin, sterile
|
15
|
￥ 4230
|
|
80424
|
μ-Slide 4 well, Poly-L-Lysine, sterile
|
15
|
￥ 4230
|
|
80425
|
μ-Slide 4 well, Poly-D-Lysine, sterile (available only on request)
|
15
|
￥ 4230
|
|
80421
|
μ-Slide 4 well, hydrophobic, uncoated, sterile
|
15
|
￥1440
|
|
80426
|
μ-Slide 4 well, ibiTreat, tissue culture treated, sterile
|
15
|
￥1440
|
Applications/应用:
Cultivation and microscopy of cell cultures
Transfection assays
Fluorescence microscopy of both living and fixed cells
Live cell imaging over extended time periods
Technical Features/技术特征:
Open μ-Slide with 4 independent wells
Excellent optical quality for high-end microscopy
Compatible with staining and fixation
ibiTreat surface for optimal cell adhesion
Made of biocompatible plastic material – no glue and no leaking
Specifications/规格:
|
Number of wells
|
4
|
|
Dimensions of wells
(w x l x h) in mm
|
21.2 x 11.0 x 9.3
|
|
Recommended volume per well
|
700 μl
|
|
Total height with lid
|
10.8 mm
|
|
Growth area per well
|
2.2 cm2
|
|
Coating area per well
|
4.1 cm2
|
|
Bottom matches coverslip
|
No. 1.5
|
|
Bottom: ibidi Standard Bottom
|
Immunofluorescence of Human Umbilical Vein Endothelial Cells (HUVEC) in a μ-Slide 4 well
Blue: Nucleus (DAPI)
Green: VE-Cadherin (Alexa555)
Red: F-Actin (Alexa488)
